QM Drain Delmar 28" Mist (Tile-In) Linear Drain
QM Drain Delmar 28" Mist (Tile-In) Linear Drain
Sale price$359.72
Regular price$529.00 (/)
Product details
Focal Point is an authorized QM Drain Retailer!
About The QM Drain Delmar 28" Mist (Tile-In) Linear Drain
Linear Drain Standard Length. Variable positioning: Versatile, linear drains can be installed anywhere in the shower and can be combined with all standard tile formats.
About The QM Drain Delmar 28" Mist (Tile-In) Linear Drain
Linear Drain Standard Length. Variable positioning: Versatile, linear drains can be installed anywhere in the shower and can be combined with all standard tile formats.
- Base: Low profile standard Flange edge channel. Pre-sloped standard plain edge , flange edge or side outlet . Ideal for new and renovation projects and generally for all bathrooms where space is tight.
- Outlet: 2" center located outlet.
- Material: Made with stainless steel marine grade 316 from top to bottom. It makes it the perfect linear drain for your indoor or outdoor shower.
- Grate: Tile insert tray. It can accommodate any tile, stone or other flooring material up to 1/2" thick. Flange Edge bases have the option of frameless Tile-In tray. It is suitable for any thickness of flooring.
- Application: Indoor and Outdoor Shower.
- Easy cleaning: Completely removable grate and a hair strainer* (not included with Flange Edge bases) that fits inside the drain to collect hair and other debris, preventing clogged pipes.
- Easy installation: Plain Edge base is intended for use with traditional or standard waterproofing methods, utilizing a traditional clamping drain body. Waterproofing is installed before the drain base is connected. Threaded adaptor with rubber O-ring aids adjusting the height of linear drain and securing the linear drain to the drain body, equipped with adjustable feet on both sides, to help keep the drain channel in the correct position and level during installation.
